Taizhou Kayond मशीनरी कं, लिमिटेड
| न्यूनतम आदेश मात्रा: | 1 |
|---|---|
| मूल्य: | 3065 |
| प्रतिरूप संख्या।: | सीडीडी2030 | भार क्षमता: | 1-2टी |
|---|---|---|---|
| भार केन्द्र: | 500 मिमी | लिफ्ट की ऊंचाई: | 3000 मिमी |
| बैटरी की क्षमता: | 24वी/210एएच | टायर प्रकार: | पु पहिया |
| टर्निंग रेडियस: | 1738/2099 मिमी | पैकेज आकार: | 218x90x213cm |
| कांटा आकार: | 1220*100*40 मिमी | धरातल: | 30 मिमी |
| ड्राइविंग गति: | 4km/एच | ढाल: | 3 डिग्री / 5 डिग्री |
| ड्राइविंग मोटर: | 1.2KW | मोटर उठाना: | 2.2KW |
| संपूर्ण आकार: | 2170*1570*2100 मिमी | ||
| प्रमुखता देना: | Customized Electric Pallet Stacker,DC Motor Pallet Stacker,PU Wheel Balance Forklift |
||
The full electric pallet stacker is designed for efficient loading, stacking, and short-distance palletizing operations. Its simple structure offers flexible operation with excellent micro-control capabilities and high safety performance. Ideal for working in confined spaces, this stacker can access ship cabins, carriages, and containers for palletized goods handling.
| Model | CDD1030 | CDD1530 |
|---|---|---|
| Load Capacity | 1000 kg | 1500 kg |
| Lifting Height | 3000 mm | 3000 mm |
| Load Center | 500 mm | 500 mm |
| Fork Size | 1220×100×40 mm | 1220×100×40 mm |
| Ground Clearance | 30 mm | 30 mm |
| Driving Speed (Full Load) | 4 km/h | 4 km/h |
| Battery | 24V/210A | 24V/210A |
| Overall Dimensions | 2170×1570×2100 mm | 2170×1570×2100 mm |
Brand: KAD - Domestic premium control handle with functional buttons for sensitive UP/DOWN and FORWARD/BACKWARD control.
Combined key, battery indicator, and emergency switch. Functional and aesthetically designed for comfortable operation.
Strong cylinder and chain system ensures smooth fork operation. Available with 1-stage, 2-stage, or 3-stage mast options.
