Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse

Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse
Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse
Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse
बुनियादी जानकारी
उत्पत्ति के प्लेस: चीन
ब्रांड नाम: KAD
प्रमाणन: CE/ISO9001
मॉडल संख्या: CDD07B
न्यूनतम आदेश मात्रा: 1
मूल्य: $1791
पैकेजिंग विवरण: लौह फूस + प्लास्टिक फिल्म
प्रसव के समय: 7वर्क दिन
भुगतान शर्तें: एल/सी, डी/ए, डी/पी, टी/टी, वेस्टर्न यूनियन
आपूर्ति की क्षमता: 50यूनिट/माह
सबसे अच्छी कीमत अब से संपर्क करें
प्रतिरूप संख्या।: CDD07B भार क्षमता: 1-1.5 टन
भार केन्द्र: 500 मिमी लिफ्ट की ऊंचाई: 1600 मिमी
बैटरी की क्षमता: 24वी/210एएच कांटा आकार: 1220*100*40 मिमी
धरातल: 30 मिमी टर्निंग रेडियस: 1500 मिमी
ड्राइविंग गति: 4km/एच ढाल: 3 डिग्री / 5 डिग्री
मोटर चलाना: 0.8 किलोवाट मोटर उठाना: 0.8 किलोवाट
टायर का आकार: 300/250 मिमी संपूर्ण आकार: 1603*852*1155मिमी
वज़न: 266 किग्रा
प्रमुखता देना:

Electric pallet stacker 1000kg capacity

,

Full electric loading stacker 1.6m lift

,

Warehouse precision stacker with warranty

Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse

The wide-view mast and smooth vehicle shape, with multi-curved cover parts, unrestricted vision and improved working efficiency; the H-channel steel mast is resistant to bending and torsion, strong and durable, ensuring the vehicle's load capacity; the maintenance-free AC motor minimizes maintenance costs; the standard integrated handle integrates multiple functions for quick and easy operation; the front cover is easy to disassemble and various components are centrally arranged to make maintenance faster and smoother.
advantage:
1.Folding reduces the space occupied by the carriage and increases the cargo carrying capacity of the truck.
2. It can stably lock the body of the truck when going up and down the slope, avoiding slipping and increasing the safety factor.
3. It will not increase the load burden of transportation vehicles and meets the load limit requirements of urban freight transportation.
Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse 0
If you have any questions about this Semi-Electric Self-loading Stacker, please feel free to contact me via the following methods. I will be on call 24 hours a day. Thank you.
Model

CDD15D
CDD07B
CDD10E
CDD13
CDD15E
Type of Power

Li-Ion Battery
Li-Ion Battery
Li-Ion Battery
Li-Ion Battery
Battery
Max. Load
kg
1500
700
1000
1300
1500
Load Center
mm
400
400
400
400
400
Wheelbase
mm
1003
922
924
916
924
Wheel Distance: FR
mm
405/525
405/525
405/525
405/525
405/525
Wheel Distance: RR
mm
642/762
802
802
802
802
Type of Operation

Walk
Walk
Walk
Walk
Walk
Front Wheel
mm
2-Φ80×70/2-Φ80×60
φ80×70
φ80×70
2-φ80×70
2-φ80×70/2-φ80×60
Universal Wheel
mm
2-Φ50×43
Φ75×50
φ75×45
2-φ75×45
Φ75×45
Middle Wheel
mm

Φ45×30
φ45×30
2-φ45×30
Φ45×30
Driving Wheel
mm
Φ185×70
Φ185×70
φ185×70
φ185×70
Φ185×70
The Distance the Forks Extend
mm
256
158
158
158
158
Length of Outriggers
mm
791
770
770
772
780
Max. Fork Height
mm
800/900/1000/1100/1200 /1300/1500/1600
800/900/1000/1100/1200 /1300/1500/1600
800/900/1000/1100/1200 /1300/1500/1600
800/900/1000/1100/1200 /1300/1500/1600
800/900/1000/1100/1200 /1300/1500/1600
External Distance Between Forks
mm
565/685
565/685
565/685
565/685
565/685
Length of Fork
mm
1150
1195
1195
1250
1250
Thickness of Fork
mm
70
70
70
70
80
Width of Fork
mm
176.5
190
190
190
190
Overall Length
m
1586




Overall Length
mm
1851
1603
1603
1655
1657
Overall Width
mm
824/944
852
852
852
802
Overall Height (Mast Closed))
mm
1250/1350/1450/1550/1650 /1750/1950/2050
1155/1255/1355/1455/1555 /1655/1855/1955
1166/1266/1366/1466/1566 /1666/1866/1966
1163/1263/1363/1463/1563 /1663/1863/1963
1163/1263/1363/1463/1563 /1663/1863/1963
Overall Height (Max. Fork Height)
mm
1867/2067/2267/2467/2667 /2867/3267/3467
1875/2075/2275/2475/2675 /2875/3275/3475
1850/2050/2250/2450/2650 /2850/3250/3450
1861/2061/2261/2461/2661 /2861/3261/3461
1861/2061/2261/2461/2661 /2861/3261/3461
Lifting speed
mm/s
55
55
55
55
55
Descent speed
mm/s
100
100
100
100
100
Lift Motor Power
kw
2.2
0.8
1.6
1.6
2.0
Driving Motor Power
kw
0.8
0.8
0.8
0.8
0.8
Max. speed(Turtle speed / full-load)
kw/h
1/3.5
1/3.5
1/3.5
1/3.5
1/3.5
Grade Ability(Full-load/NO-load)
%
5/10
5/10
5/10
5/10
5/10
Battery Voltage
V
48
48
48
48
48
Battery Capacity
Ah
Standard configuration (15) optional (30/quick change 30)
Standard configuration (15) optional (30/quick change 30)
Standard configuration (15) optional (30/quick change 30)
Standard configuration (15) optional (30/quick change 30)
25
Battery Weight
kg
10kg/2*17kg
6/10/10
6/10/10
6/10/10
25
Total Weight(Include Battery)
kg
450/354/460/463/466 /470/480/480
266/270/274/278/282 /286/295/300
302/316/320/324/328 /332/342/347
365/369/375/378/381 /385/395/400
390/394/400/403/406 /410/420/425

Full Electric Loading Stacker 1000kg 1.3m-1.6m Lifting Height High Quality Precision Stacker for Warehouse 1
